EP-2 3.0 Boost
Specs
| General Info | |
| Model | EP-2 3.0 Boost |
| Bike Weight | 32.3 kg (71.2 lbs) |
| Gross Weight | Approx. 40.3kg (88.8 lbs) |
| Max Load Capacity | 150kg (330 lbs) |
| Ride Height | 5'5" - 6'2" (165cm - 190cm) |
| Waterproof Ratings | IPX7(Waterproof Wiring) IPX6(Display & Lights) IPX5(Motor & Controller) IPX5(Battery Box) |
| Terrain | Tarmac Roads & Bicycle Routes Gravel-Paved Paths Sandy Beaches & Grass Country Roads & Paved Trails |
| Pedal Assist | 5 Levels |
| Real-World Range | 120 km(PAS 1) 100 km(PAS 3) 80 km(PAS 5) |
| Fold | Yes |
| Certification | CE EN15194 by TUV certification |
| Frameset | |
| Frame Style | Foldable Frame |
| Frame Material | Step-through Design, Magnesium Alloy with Integrated Battery |
| Fork | Hydraulic, Adjustable Lockout, Aluminum & Steel Construction |
| Front Suspension | 50mm Travel |
| Wheel Set | |
| Tires | 20" × 4.0" Urban Hybrid Tires |
| Puncture Protection | 3mm Anti-Puncture Layer |
| Wheels | 20-inch, Double-Wall Aluminum, 36-Hole, 12-Gauge Spokes, Black |
| E-Bike System | |
| Motor | 48V Hub Motor |
| Max Torque | 75Nm |
| Assist System | Torque Sensor |
| Battery | 48V 13.5Ah (648Wh), 21700 Cells with BMS Protection |
| Display | 3.5" LCD Color Display, ENGWE-Designed, Mid-Position , with Bluetooth |
| ENGWE App | App Control |
| Charger | 54.6V 4A Output |
| Front Light | 30 Lux with Integrated E-Horn |
| Rear Light | Automatically brightens When Braking or Shaking |
| Brakes | |
| Brake Type | Hydraulic, Dual-Piston |
| Disc Rotor | 180mm Front & Rear |
| Drivetrain | |
| Chain | Anti-Rust Bicycle Chain, 1/2" x 3/32", 124 Links |
| Chainring | 48T |
| Crank | 170mm |
| Rear Derailleur | Shimano Tourney RD-TY300, 7-Speed |
| Shifter | Shimano SL-M315-7R |
| Cassette | 7-Speed, 14T-28T |
| Pedals | Boron Steel, Non-Foldable |
| Cockpit | |
| Saddle | ENGWE Soft Saddle |
| Seat Post | 10-Level Adjustable |
| Handlebars | 680mm Width |
| Stem | Foldable |
| Seat Clamp | Quick-Release |
What's in the Box?
| EP-2 3.0 Boost E-bike | *1 |
| 13.5Ah Lithium-Ion Battery | *1 |
| 54.6V 4A Battery Charger | *1 |
| Front & Rear Fenders | *1 |
| Bike Kickstand | *1 |
| Rear Rack | *1 |
| Pedals | *2 |
| Assembly Tools | *1 |
| User Manual | *1 |
Size
| Rider Height | 5.5 (ft) - 6.2 (ft) |
| Payload Capacity | 150 kg (330lbs) |
| Gross Weight | Approx. 40.3kg(88.8 lbs) |
| Package Dimensions (LWH) | 137.5cm*29.5cm*65cm |
| A-Wheelbase | 110 cm |
| B-Total Length | 166 cm |
| C-Reach | 40.6 cm |
| D-Standover Height | 68 cm |
| E-Minimum Saddle Height | 88 cm |
| F-Maximum Saddle Height | 104 cm |
| G-Minimum Handlebar Height | 126 cm |
| H-Maximum Handlebar Height | 135 cm |
Please note: There may be a difference of 0~5 cm between measured and actual data.
| Folded Size |
97*53*81 cm |
| A-Height | 81 cm |
| B-Length | 97 cm |
| C-Width | 53 cm |
Please note: There may be a difference of 0~5 cm between measured and actual data.
